SIZE

0.6

1.2

2.5

5

10

20

Static Torque, NM

5.5

11

22

45

90

170

Coil Voltage (typical), DCV

24

24

24

24

24

24

Coil Power (at 20C), W

11

15

20

25

35

45

Max. Revolution, RPM

5,000

5,000

4,500

4,000

3,000

2,500

Bore

Dia. (Rotor, Arm Hub), dH7

12

15

20

25

30

40

keyway, bXT

4x1.5

5x2

5x2

7x3

7x3

10x3.5

Key (Arm Hub) Width X Height

4X4

5X5

5X5

7X7

7X7

10X8

Diameter

AH8

80

100

125

150

190

230

B

72

90

112

137

175

215

CH7

35

42

52

62

80

100

D

67

85

106

133

169

212

E

63

80

100

125

160

200

Fj6

38

45

55

64

75

90

G

33

38

48

55

65

78

J

3-M4

3-M4

4-M4

4-M4

4-M5

4-M6

K

5

6

7

7

10

10

Length

L

51.5

60

71

86.5

103.5

124.5

M

22

24

27

30

34

40

N

20

25

30

40

50

60

P

2

2.5

3

3.5

4

5

Q

3.5

4.3

5

5.5

6

7

R

24

26.5

30

33.5

37.5

44

T

2

2.5

3

3.5

4

4.5

Air Gap, a

0.2

0.2

0.2

0.2

0.3

0.4

Weight, kg

0.8

1.4

2.5

4.3

8

15
